- Type:Reverse tricycle
- Certification:DOT
- Driving Type:Motorized
- Body Type:Open
- Power:>1000W
- Voltage:60V
- Displacement:151 - 200cc
- Use For:Passenger
- Grade Ability:≥25°
- Payload Capacity:100-200kg
- Maximum Speed:≥70Km/h
- Curb Weight:100-200kg
- Tire Size:140/60-14 235/30-14
- Brake System:Front disc+Rear dsic
- Passengers:2
- Fuel Tank Capacity:10-20L
- Brand Name:JASSCOL
- Place of Origin:Zhejiang, China
- Size:2025*1220*1000mm
- Color:Red Bule Black White
- Brake:Disck Brake
- Max speed:84km/h
- Loading capacity:150KGS
- Wheelbase(mm):1500mm
- Rating power:6.8kw/7500rpm
- Overall size:2025*1220*1000mm
- Carton size:2000*+1150*800mm
EPA Approved
1. Engine type: 177.3cc balance shaft engine,single cylinder,4 stroke, Air Cooling, Automatic with reverse
2. Max. Power:6.8kw/7500rpm
3. Max.Torque:10/6000r/min
4. Compression Ratio: 10:1
5. Bore*Stroke(mm):62.5*57.8
6. Ignition Method: CDI
7. Lubrication Method: pressure spray
8. Min.Fuel Consumption:367g/kw.h
9. Start Method: electric start
10.Clutch Method: dry automatic centrifugal
11.Gearshift Method/Change Gear Method:CVT
12.Lubricating Oil:10W/40SF
13.Overall Size: 2025x1220x1000mm
15.Wheel Bases: 1500mm
16.Distance of wheel:1050mm
17.N.W./G.W.: 156 kgs/168kgs
18.Max. Load:150kgs
19.Max. speed : 80 km/h
20.Brake: F/R disc brake
21.Tire:Front 140/60-14, Rear:235/30-14
22.Fuel:15L/Unleaded gasoline≥ RQ92
23.Conveyance: Qty/40' HQ: 22pcs
