- Place of Origin:Zhejiang, China
- Brand Name:Jasscol
- Model Number:AL6061
- Fork Material:Steel
- Rim Material:Steel
- Gears:Single Speed
- Fork Suspension:Yes
- Gross Weight:35kgs
- Net Weight:28kgs
- Wheel Size:14"
- Frame Material:Steel
- Braking System:Disc Brake
- Frame Type:Hard Frame (Non-rear Damper)
- Pedal Type:Ordinary Pedal
- Length (m):1.6
- Load Capacity:120kg
- Tire Width:20*2.5"
- Battery:36V 10AH
- Range:40-60km
- Charger:6-8 hours
- Motor:JIABO, 36V 250W, rear drive
- Certification:ce
| Frame | 14", AL6061 |
| Fork: | Suspension fork, Steel |
| Brake: | F/R: Mechanical disc brake |
| Brake lever: | STAR UNION, 47DPP |
| Handle bar: | Steel |
| Stem: | Steel |
| PEDAL: | Plastic |
| Saddle: | QF, QF-2034 |
| Grip: | Integrated with throttle |
| Tire: | JZ, 14*2.25 |
| Crank: | Steel, 1/8*48T*152 |
| Shifters: | Single speed |
| Rear derailleur: | Single speed |
| Chain/Belt: | 1/2*94 |
| Flywheel : | 1/2×1/8×16T |
| Light: | F/R: reflector |
| Display: | Integrated with throttle, LED |
| Motor: | JIABO, 36V 250W, rear drive |
| Battery: | 36V 10AH with Chinese cell |
| Charger: | 36V2A |
| Kickstand: | With |
| Distance: | 40-60km |
| Max speed: | 25km/h |
| N.W. | 28kgs |
| Max Load: | 120kgs |
| Colour: | TBD |
BASED ON TECHNOLOGY DEVELOPMENT CENTER IN TAIWAN, WITH TAIWAN'S ENGINEERING
DESIGN AND MACHINING TECHONLOGY, POSITIONING A HIGH STANDARD OF QUALITY
| PRODUCT CATEGORIES |
| ABOUT COMPANY |
| SHIPPING & PAYMENT |
| TRANSACTION PROCESS |
| FAQ |
1. What is the minimum order(MOQ)?
5-15 pcs per model
2. What is the production time?
Production time: 35-45 days.
3. Can you please offer me the best price based on our order quantity?
Sure, we always offer customer our factory direct sales price.
4. What is the payment term if we place the order?
T/T , L/C, West Union, etc, are all avaliable.
