- Place of Origin:Zhejiang, China
- Brand Name:Jasscol
- Model Number:LB14
- Fork Material:Aluminum Alloy
- Rim Material:Aluminum Alloy
- Gears:9 SPEED
- Fork Suspension:Yes
- Gross Weight:28kgs
- Net Weight:17.5kgs
- Wheel Size:26"
- Frame Material:Aluminum Alloy
- Braking System:Disc Brake
- Frame Type:Hard Frame (Non-rear Damper)
- Pedal Type:Ordinary Pedal
- Length (m):1.7
- Load Capacity:150KG
- Tire Width:20*2.15"
- Battery:36V/16Ah Lithium Battery
- Range:40-60km
- Charger:6-8 hours
- Motor:36V/350W
- Certification:ce
Detailed Information
| Electric System | Main Components | ||
| Motor | 250W36V,Rear hub Brushless motor | Frame | 6061 Alloy Aluminum |
| with waterproof connection cable | Rim/Tyres | Aluminum/700c*25c | |
| Battery | 36V/7Ah Lithium Battery, LG/Samsung cells | Front fork | Aluminium Rigid Fork |
| Light | F&R LED light available | Brake | Mechanical Disc-brake |
| Displayer | LCD color display | Derailleur | 9 Speed Shimano Cassette |
| Controller | 36V13A integrated controller | Speed gears | 9 Speed gear Shimano |
| Sensor | Torque sensor, pedal assisted | Handlebar/stem | Alloy aluminum |
| Charger | 100~240V, 36V2A Smart charger | Spoke | 13g Stainless steel |
| Plug as final market requirement | Chain | Rust resistant chain | |
| Charge time | 3-5 hours | Rack | Optional |
| Throttle | No | Fender | Optional |
| Performance | Performance | ||
| Speed | 25Km/h | Max Load | 120Kgs |
| Range | 45km+ by PAS | N.W / G.W | 17.5kg / 28kg |
| Carton Size | 1600*280*825mm | Container Load | 168pcs/40HQ |
BASED ON TECHNOLOGY DEVELOPMENT CENTER IN TAIWAN, WITH TAIWAN'S ENGINEERING
DESIGN AND MACHINING TECHONLOGY, POSITIONING A HIGH STANDARD OF QUALITY
| PRODUCT CATEGORIES |
| ABOUT COMPANY |
| SHIPPING & PAYMENT |
| TRANSACTION PROCESS |
| FAQ |
1. What is the minimum order(MOQ)?
5-15 pcs per model
2. What is the production time?
Production time: 35-45 days.
3. Can you please offer me the best price based on our order quantity?
Sure, we always offer customer our factory direct sales price.
4. What is the payment term if we place the order?
T/T , L/C, West Union, etc, are all avaliable.
